• * Galvanic isolation
• * No external power supply for configuration
• * Write or read the configuration off-line by just connecting a PC
• * Fault signal on sensor break or short circuit
• * 2 wire technology, 4 to 20mA analogue output
• * High accuracy in total ambient temperature range
• * Customer specific measurement range setting or expanded SETUP

• Range: 0-20 mg/L, 0-200%, 0-400 hPa
• Resolution: 0.01 mg/L, 0.1%, 1 hPa
• Output signal: 4 ~ 20 mA; Relay; RS485
• Power supply: AC220V±10%; 50Hz/60Hz
• Communication protocol: MODBUS-RTU standard (customizable)
• Operating temperature: 0~60 °C

• IIoT capability
• Integrated pressure sensor with stainless steel diaphragm
• Accuracy 0.25% standard (finer accuracies are available)
• OLED color display
• Easy to use via a mobile application in real time
• Possibility to set parameters via a dashboard
• 4 relays, switch-on and switch-off points can be set independently
• Possibility to program a delayed measurement

• Universally progammable with HART-protocol for various input signals
• Two-wire technology, analogue output 4 to 20mA
• Highly accurate in entire operating temperature range
• Wide voltage supply range
• Customer specific measurement range settings
• Simple and user friendly software
• Multiparametric backlight rotatable LCD display

Applications :

• Automatisation
• Boiler
• Oil Furnace
• Engines

Products Specifications :

• Setpoint repeatability : +/- 2% of FSR
• Switch output : NO,NC,SPDT contacts
• Enclosure : Rolled aluminium
• Storage temperature :-20°C to +80°C
• Tmax : 150°C

• * Dimensions:   44mm×22.5mm(Φ×H)
• * Output:   4 to 20mA
• * Supply voltage:   11.5 to 35VDC (non-Ex-Area) 11.5 to 30VDC (Ex-Area)
• * Input:   RTD, TC, Ohm, mV
• * Operation:   HART-protocol
• * Galvanic isolation(In/Out):  2KVAC
• * Installation:  sensor head Form B

• Hose material: Metal/ rigid plastic tube made of PCV, PP or PVDF
• Liquid type: Water/Other (fluids without solid particles or impurities)
• 0-75° (no surface freezing)
• Low speed cut-off value: 0.1m/s
• Display: 256*128, LCD
• Response time: 0.5-60s
• Accuracy: +/-2%, (+/-1% after calibration)
• Data storage period: 300ms
• Memory for data saving: EEPROM, data storage more than 10 years
• I/O power supply: M12 type aviation plug
• Output: 4-20mA
• Communication: Modbus RS485
• Option for output: OCT, alarm relay
• Power supply: 10-24VVDC
• Electrical power : <3W
• Ambient temperature : -10° to 60°C
• Cable length: 2m, PT100 sensor cable length is 9m

Features

• Range: 0.01 electrode: 0.02~20.00us/cm
• 0.1 electrode: 0.2~200.0us/cm
• 1.0 electrode: 2~2000us/cm
• 10.0 electrode: 0.02~20ms/cm
• Output signal: 4 ~ 20 mA; Relay; RS485
• Power supply: AC220V±10%, 50Hz/60Hz
• Operating temperature: 0~60°C
• Accuracy : ± 2 % PE
• Measuring medium: Liquid
• Relay output: 250 VAC, 3A

• Storage temperature ; Atmospheric temperature
• Operating ambient temperature : -20°C to +60° C
• Media Temp : for rubber diaphragms 80 degree C max, higher with metal diaphragms
• Can be offered for higher temperatures with other capsule combinaisons
• Setpoint repeatability : ± 1% of FSR
• Enclosure : Die cast aluminium to IP 66
• Switch output : SPDT, DPDT, hermetically sealed, gold plated contacts
• Process connection : 1/4 "BSP standard, other options like flanges, triclover clamps, diaphragm seals available

• Communication : e-HART
• Output : 4 to 20mA
• Supply voltage : 7.5 to 45VDC
• Input : RTC, TC, Ohm, mV
• Cold junction : Internal
• Accuracy (Pt100) : <0,2K or 0,08%
• Influence of ambient : Negligible
• Load influence : Negligible
• Power supply influence : Negligible
• Resolution : 0.3uA
• Galvanic isolation (In/Out) : 2KVAC
• Installation : DIN Rail
