SE Series sub-miniature temperature switches
Applications :
- Automatisation
- Boiler
- Oil Furnace
- Engines
Products Specifications :
- Setpoint repeatability : +/- 2% of FSR
- Switch output : NO,NC,SPDT contacts
- Enclosure : Rolled aluminium
- Storage temperature :-20°C to +80°C
- Tmax : 150°C
-
Garanties sécurité
-
Politique de livraison
-
Politique retours
SE series sub-miniature temperature switches are low cost options. They are generally used where size is a constraint. Typical applications are to sense temperature. Can also be used for serval other applications e.g automation, boiler, oil furnace, engine etc.
SE
Reviews
No customer reviews for the moment.
