• Pressure range: 0 to 700 bar
• Media: Oil or Water (optional)
• Oil tank: 100 ml
• Very fine adjustment valve for optimum resolution
• Material: Body: Stainless steel ~ Fittings: Stainless steel ~ Seals: Buna-N
• Instrument test connections: 1/4 G (F)
• Standard connections: 3/8 G (F)
• Dimensions: 240 × 185 x 95 mm 1.8 kg
• Ease of use, ergonomics & reliable performance

• 12 Units: kPa, Pa, PSI, Kg / cm², Bar, mBar, MPa, Pa ...
• Display: Large LCD screen with 4 DIGIT
• Keys: On / Off, Reset, backlight
• Connection: 1/4 ’’ G
• Dial size: 65 mm
• All stainless steel fitting and housing
• Max pressure recording & min.
• Battery alarm function
• Pressure diagram in%
• Ease of use, robust design and reliable performance
• Lithium battery 1 year autonomy in 24 hour operation

In process of supply - delivery within 10 days

Order a calibration certificate >

• Pressure range : 95% of vacuum up to 70 bar
• Media : Air
• Adjustment resolution: 0,1 mbar
• Material : Body: SS & aluminum ~ Ram/adapters: SS ~ Seals: Buna-N
• Connections: 1/4NPT F, 1/4BSP F, or M20X1.5 F
• Dimensions: Base : 315×198 ~ Height ×140 (mm) 2.6 kg
• User-friendly, robust design and reliable performance

• Pressure: relative
• Details: 0.025% of full scale
• Connexion : 1/2" G (M)
• 11 Units: Pa, kPa, MPa, PSI, Kg / cm², Bar, mmBar, cmH20 ...
• Display: Large LCD screen 5 or 6 Digit & Bargraph in%
• 7 function keys
• Temperature compensation from 0 to 50 ° C
• 60 hour rechargeable lithium battery
• Integrated data logger
• Clean design & high performance
• CE & Exia II CT4Ga approved
• Calibration certificate with factory traceability

• Pressure range : 95% of vacuum up to 4 bar
• Media : Air
• Adjustment resolution: 0,001 mbar
• Material : Body: SS & aluminum ~ Ram/adapters: SS ~ Seals: Buna-N
• Connections: 1/4NPT F, 1/4BSP F, or M20X1.5 F
• Dimensions: Base : 273×258 ~ Height ×140 (mm) 2.8 kg
• User-friendly, robust design and reliable performance

• Accuracy: ± 0.2% of full scale
• Units: kPa, Pa, PSI, Kg / cm², Bar, MPa
• Display: Large LCD screen with 5 DIGIT + Pressure graph
• Keys: On / Off, Reset, backlight
• Connection: 1/4 ’’ NPT, 1/4 ’’ G (or customizable)
• Dial size: 100 mm
• Max & min pressure recording
• Battery alarm function
• Ease of use, robust design and reliable performance
• Lithium battery 1 year autonomy in 24 hour operation

• Storage temperature ; Atmospheric temperature
• Operating ambient temperature : -20°C to +60° C
• Media Temp : for rubber diaphragms 80 degree C max, higher with metal diaphragms
• Can be offered for higher temperatures with other capsule combinaisons
• Setpoint repeatability : ± 1% of FSR
• Enclosure : Die cast aluminium to IP 66
• Switch output : SPDT, DPDT, hermetically sealed, gold plated contacts
• Process connection : 1/4 "BSP standard, other options like flanges, triclover clamps, diaphragm seals available

• Accuracy: ± 0.2% of full scale
• Units: kPa, Pa, PSI, Kg / cm², Bar, MPa
• Display: Large LCD display with 5 DIGIT + Pressure bar graph
• Keys: On / Off, Reset, backlight
• Connection: 1/4 ’’ NPT
• Dial size: 80 mm
• Max & min pressure recording
• Battery alarm function
• Ease of use, robust design and reliable performance
• 2x Lithium battery



CALIBRATION CERTIFICATE >>

• Pressure range : 0 up to 700 bar
• Media : Oil or water
• Adjustment resolution: 200 mbar
• Material : Body: SS & aluminum ~ Ram/adapters: SS ~ Seals: Buna-N
• Connections: 1/2 BSP F
• Dimensions: Base : 384×198 ~ Height ×180 (mm) 4,7 kg
• User-friendly, robust design and reliable performance

• Pressure range: -0.9 to 60 bar
• Media: Air
• Resolution: 1 mbar
• Connections Standard instruments: 3/8 BSP F
• Connections Instruments test: 1/4 BSP F
• Nylon hose 1 meter with suitable connector
• Ergonomics & Ease of use
• Robust Design & Stable Performance
• No specific maintenance to be expected

• Measuring range: 10kPa-1MPa
• Output signal: 4-20mA, 4-20mA + HART ...
• Accuracy: ± 0.1% URL, ± 0.075% URL
• Substrate temperature: -40-120 ° C
• Measurement: pressure, level, differential pressure, density, flow
• Protection class: IP67
• Diaphragm material: SUS316L, Hastelloy C ...
• Stability: ± 0.2% of URL / 5 years
• Process connection: DN50 PN10, DN80 PN10, DN100 PN10
• Certificates: CE, EX- test certificate

• Pressure range: -0.9 to 2 bar
• Media: Air
• Resolution: 0.05 mbar
• Connections Standard instruments: 3/8 BSP F
• Connections Instruments test: 1/4 BSP F
• Nylon hose 1 meter with suitable connector
• Ergonomics & Ease of use
• Robust Design & Stable Performance
• No specific maintenance to be expected

• Measuring range: 200Pa-40MPa
• Output signal: 4-20mA, 4 ~ 20mA / HART, client
• Reference accuracy: ± 0.075% URL, optional ± 0.05% URL
• Fluid temperature: -40-120
• Measuring fluid: level, density and pressure of the liquid, gas or vapor
• Protection class: IP67
• Diaphragm material: SUS316L, Hastelloy C
• Stability: ± 0.2% URL / 60 months
• Process connection: M20 * 1.5 (M), 1 / 2-14NPT (F), 1 / 4-18NPT (F)
• Approvals: ATEX, MC, NEPSI,, CE

• Generation and measurement of electrical signals
• Generation and measurement of temperatures
• Pulse frequency generation and measurement
• Automatic switch test
• 24 V loop power supply
• RS-232 communication
• Data recording
• Documentation and automated procedures
• Communication Hart
• Intelligent pressure external modules
