• MID
• Facilité d'installation & d'utilisation
• Précision & grande stabilité
• Energie thermique & frigorifique
• Design et compact
• Montage verticale ou horizontale
• Ecran LCD 8 digit
• Durée de vie de la batterie supérieur à 10 ans
• Communication optique incluse
• Communication RS485 ou M-Bus

• Accuracy: 1%
• Non-intrusive transducers
• DN20 to DN6000 ~ depending on type of transducers
• Rechargeable battery, Autonomy 50 hours
• Data logger
• Communication: RS-485 Modbus RTU
• Output: 4-20mA
• IP67 flowmeter ~ IP68 transducers
• Compact & Robust
• Dimensions: 270 × 215 × 175 mm ~ Weight: 3 kg
• 2x Non-intrusive transducers -35 ° C to 85 ° C
• Other output (optional): Pulse, Relay

• Hose material: Metal/ rigid plastic tube made of PCV, PP or PVDF
• Liquid type: Water/Other (fluids without solid particles or impurities)
• 0-75° (no surface freezing)
• Low speed cut-off value: 0.1m/s
• Display: 256*128, LCD
• Response time: 0.5-60s
• Accuracy: +/-2%, (+/-1% after calibration)
• Data storage period: 300ms
• Memory for data saving: EEPROM, data storage more than 10 years
• I/O power supply: M12 type aviation plug
• Output: 4-20mA
• Communication: Modbus RS485
• Option for output: OCT, alarm relay
• Power supply: 10-24VVDC
• Electrical power : <3W
• Ambient temperature : -10° to 60°C
• Cable length: 2m, PT100 sensor cable length is 9m

For all clear, non biphasic liquids and all types of pipes from DN20 to DN 1200 :

• Measurement accuracy 1% F.S
• Communications : 4~20 mA & RS485 Modbus
• Programmable data logger 16 GB SD card
• Battery 16 hours autonomy
• Non-invasive transducers Stainless steel IP68
• Mounting rails for optimal measurement
• Energy metering included
• 2x TT02 IP68 transducers
• -40 °C ~ 80 °C (130°C optional)
• Suitable for pipes DN 20 mm to DN 1200 mm
• Mounting rails with strip and clamps
• Standard cable length: 5 meters
• 2x non-intrusive PT100 IP68 temperature sensors
• Measurement of thermal & cooling energy

• High measurement accuracy: Accuracy: 0.5%
• Wide measuring range: DN15 to DN6000
• Energy meter: Measurement of thermal and cooling energy
• Wide temperature range: Fluid from -30 ° C to 160 ° C
• Multiple communication interface as standard:
• Outputs: RS-485 Modbus RTU ~ 1x 4-20 mA ~ 1x Pulse ~ 1x Relay
• Inputs: 3x 4-20mA (acquisition of temperature, pressure, level signals, etc.)
• Multiple materials and pressures available:
• Carbon steel, 304 stainless steel, 316 stainless steel, 1.0 Mpa, 1.6 Mpa, 2.5 Mpa
• IP68 protection - Fully waterproof: Does not fear splashing water or humid environments
• Waterproof keyboard: 4 keys - settings and multiple functions

• Hose material: Metal/ Rigid plastic tube made of PCV, PP or PVDF
• Liquid type: Water/Other (fluids without solid particles or impurities)
• 0-75° (no surface freezing)
• Low speed cut-off value: 0.1m/s
• Display: 256*128, LCD
• Response time: 0.5-60s
• Accuracy: +/-2%, (+/-1% after calibration)
• Data storage period: 300ms
• Memory for data saving: EEPROM, data storage more than 10 years
• I/O power supply: M12 type aviation plug
• Output: 4-20mA
• Communication: Modbus RS485
• Option for output: OCT, alarm relay
• Power supply: 10-24VVDC
• Electrical power : <3W
• Ambient temperature : -10° to 60°C
• Cable length: 2m, PT100 sensor cable length is 9m
